ANDREW / COMMSCOPE F4PNMV2 F4PNMV2 Type N Male for 1/2 in FSJ4-50B cable

ANDREW / COMMSCOPE F4PNMV2 F4PNMV2 Type N Male for 1/2 in FSJ4-50B cable

ANDREW / COMMSCOPE F4PNMV2 F4PNMV2 Type N Male for 1/2 in FSJ4-50B cable
ANDREW / COMMSCOPE
F4PNMV2
$1,045.12
IVA incluido
Agotado

Llamar Llamar por Teléfono 81 1107 2808
MensajeWhatsapp Solicitar Información por Whatsapp
MensajeWhatsapp Solicitar Información por Correo

F4PNMV2 Type N Male for 1/2 in FSJ4-50B cable F4PNMV2

General Specifications
  • Interface: N Male
  • Body Style: Straight
  • Brand: HELIAX®
  • Mounting Angle: Straight
Electrical Specifications
  • Connector Impedance: 50 ohm
  • Operating Frequency Band: 0 – 12000 MHz
  • Cable Impedance: 50 ohm
  • 3rd Order IMD typical: -120 dBm @ 910 MHz
  • 3rd Order IMD Test Method: Two +43 dBm carriers
  • RF Operating Voltage maximum (vrms): 707.00 V
  • dc Test Voltage: 2000 V
  • Outer Contact Resistance maximum: 0.30 mOhm
  • Inner Contact Resistance maximum: 2.00 mOhm
  • Insulation Resistance minimum: 5000 MOhm
  • Average Power: 0.6 kW @ 900 MHz
  • Peak Power maximum: 10.00 kW
  • Insertion Loss typical: 0.05 dB
  • Shielding Effectiveness: -110 dB
Dimensions
  • Nominal Size: 1/2 in
  • Diameter: 23.62 mm   |   0.93 in
  • Length: 50.80 mm   |   2.00 in
  • Weight: 163.00 g   |   0.36 lb

F4PNMV2 Type N Male for 1/2 in FSJ4-50B cable F4PNMV2

28-10-2025 19:22:51 SSN3 U-0

ANDREW / COMMSCOPE
F4PNMV2
