ANDREW / COMMSCOPE 400BPTRC 400BPTR-C Conector TNC Macho en ángulo para cable CNT-400

400BPTRC Conector TNC Macho en angulo para cable CNT-400, RG-8 400BPTR-C

General Specifications
Interface TNC Male
Body Style Right angle
Brand CNT®
Electrical Specifications
Operating Frequency Band 0 – 6000 MHz
Cable Impedance 50 ohm
Connector Impedance 50 ohm
RF Operating Voltage maximum (vrms) 500.00 V
dc Test Voltage 1500 V
Outer Contact Resistance maximum 0.40 mOhm
Inner Contact Resistance maximum 1.50 mOhm
Insulation Resistance minimum 5000 MOhm
Peak Power maximum 5.00 kW
Insertion Loss typical 0.05 dB




400BPTR-C Conector TNC Macho en angulo para cable CNT-400, RG-8 400BPTRC
