ANDREW 5NPX1006F 5NPX1006F Antena Multi Haz de 10 Puertos 10x 1710?2180 MHz 5x 10-14° HPBW
ANDREW
5NPX1006F
$379,401.07
IVA incluido
Agotado

5NPX1006F Antena Multi Haz de 10 Puertos 10x 1710?2180 MHz, 5x 10-14° HPBW 5NPX1006F

Electrical Specifications
Frequency Band MHz1710–19201920–2180
Gain dBi21.722.3
Beamwidth Horizontal degrees1312
Beamwidth Vertical degrees11.910.9
Beam Tilt degrees66
USLS (First Lobe) dB1416
Front-to-Back Ratio at 180° dB3234
CPR at Boresight dB1010
Isolation Same Beam dB2525
VSWR | Return Loss dB1.43 | 15.01.43 | 15.0
PIM 3rd Order 2 x 20 W dBc-150-150
Input Power per Port maximum watts300300
Polarization±45°±45°
Impedance50 ohm50 ohm

5NPX1006F Antena Multi Haz de 10 Puertos 10x 1710?2180 MHz, 5x 10-14° HPBW 5NPX1006F
